Price: $75.82
Canare Digital Audio Impedance Panel Mount Transformers 110 - 75 ohm Impedance Transformer Panel Mount Version FEATURES: SMPTE 276M and AES3 Transmission Standard Coaxial transmission of 2 Channel Digital Audio Allows longer cable runs than 110 ohm twisted pair AES/EBU Signal distribution using Canare 75 ohm Video Patchbays APPLICATIONS: Post Production Suites Recording Studios AES/EBU Digital Audio Routing GENERAL SPECIFICATIONS Bandwidth: 0.1 - 6MHz Maximum Voltage: 5Vp-p VSWR: <1.1 Insertion Loss: <0.3dB 110 ohm Port (Balanced): XLR3 Female 1-Shell, 2-Hot, 3-Cold 75 ohm Port (Unbalanced): Canare 75 ohm BNC Receptacle
110 - 75 ohm Impedance Transformer Panel Mount Version
APPLICATIONS:
GENERAL SPECIFICATIONS
