Marshall Electronics CV-USB-RS485 USB to RS485/422 Adapter CV-USB-RS485

The Marshall Electronics CV-USB-RS485 is a USB to RS485/422 adapter. Compatible with CV502, CV505, CV565, CV343, CV345, CV365, CV350, and CV225 cameras. USB Type-A for data output and terminal pin assignment,

Features:

• Compatible with CV502, CV505, CV565, CV343, CV345, CV365, CV350, and CV225 cameras
• USB Type-A for data output and terminal pin assignment
• 5 x DB9 male connectors

Specifications:

• Compatible Cameras
• Marshall Electronics CV502, CV505, CV565, CV343, CV345, CV365, CV350, and CV225 cameras

  USB Type
• USB Type-A for data output and terminal pin assignment

  Connectors
• 5 x DB9 male

  Output Signal
• DB9 Connector 1: T/R+
• DB9 Connector 2: T/R-
• DB9 Connector 3: RXD+
• DB9 Connector 4: RXD-
• DB9 Connector 5: Ground

  RS-422
• RS-422 full-duplex
• DB9 Connector 1: Send(A+)
• DB9 Connector 2: Send(B-)
• DB9 Connector 3: Receive(A+)
• DB9 Connector 4: Receive(B-)
• DB9 Connector 5: Ground Wire

  RS-485
• RS-485 half-duplex
• DB9 Connector 1: RS-485(A+)
• DB9 Connector 2: RS-485(B-)
• DB9 Connector 3: Empty
• DB9 Connector 4: Empty
• DB9 Connector 5: Ground Wire

  Shipping
• Weight: 0.1 lb
• Dimensions (LxWxH): 4.2 x 4 x 1.5"
