Shure CVL-B/C-TQG CVL Centraverse Lavalier Condenser Mic CVL-B/C-TQG

The Centraverse Lavalier (CVL) offers convenience and performance in an easy-to-use, clip-on cardioid condenser microphone that features simple,
no-nonsense setup made for the presenting professional. Precision-engineered for years of use in any Shure wireless system, its compact size is ideal for presenting situations where visibility is a major concern. The unidirectional (cardioid) pickup pattern rejects unwanted noise for superior source quality and vocal reproduction.

Available Models:
CVL-B/C-TQG: Centraverse Lavalier Condenser Microphone with TA4F (TQG) Connector + Tie Clip
BLX1288/CVL: BLX Wireless Vocal/Lavalier Combo System
BLX188/CVL: BLX Wireless Dual Lavalier Combo System
BLX14/CVL: BLX Wireless Presenter System

Features:

• Miniature clip-on lavalier microphone for low visibilty
• Permanently charged electret condenser element for clear vocal reproduction
• Unidirectional (cardioid) polar pattern rejects unwanted noise for improved sound quality
• Included tie clip allows hands-free use perfect for presenters
• TA4F (TQG) connector seamlessly integrates with Shure wireless bodypack systems
• Included windscreen reduces plosive, wind and breath sounds
• Tailored frequency response optimized for public speaking and presentation
• Legendary Shure precision engineering for durability and performance

Specifications:

• Type: Electret Condenser
• Frequency Response: 50 to 20,000 Hz
• Polar Pattern: Unidirectional (Cardioid)
• Output Impedance @ 1 kHz, typical: 600 Ohm


• Audio Output Level: -43.5 dBV/Pa (Measurements taken using RK100PK preamp set @ 0 dB using 8k bias resistor)
• Signal-To-Noise Ratio @ 1 kHz: 72 dB
• Maximum SPL 1000 Ohm load, @ 3% THD: 139.0 dB
• Dynamic Range @ 1 kHz, 1000 Ohm: 117.0 dB
• Equivalent Output Noise Typical, A-Weighted: 22 dB


• Power Requirements: +5 V DC (nominal), 10 V maximum (DC bias)
• Polarity: Positive pressure on diaphragm produces positive voltage on pin 3 with respect to pin 1
• Cable: 1.3 m (50 in.)
• Connector: TA4F
• Net Weight: 25 g (0.88 oz.)
