Thor H-1SDI-ATSC-IPLL Low Latency HD-SDI ATSC Modulator & IPTV Server 1 Ch THR-1SDI-ATSC-L
70 ms low latency encoding from any HD-SDI video source. Distribute any live HD-SDI video source as an ATSC compatible 8VSB channel viewable on any digital TV set. Broadcast headend type device useful for any type of video encoding & distribution. Supports HD inputs up to 1080p60 and encodes in either MPEG-2 or H.264 for more modern applications. All settings are configurable through either the front panel LCD or through a web browser on a dedicated network port. A second network port is provided for IPTV streaming output that can directly feed any standard IPTV system. Also provides broadcasting type DVB-ASI input and output for added flexibility and integration with other broadcasting components. Multi-purpose system that can be used as a standard broadcast encoder with ASI out, as a digital HDTV channel modulator with 8VSB out, or as an IPTV server with UDP unicast and IGMP multicast output. High power RF channel output can be adjusted from 10 - 40 dBmV to provide enough power for approximately 100 televisions. 1 Channel encoder modulator system.
